EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
Schedules Menu
UsetheSchedulesmenutocreateprogramstoschedulestartandstoptimestoautomaticallyrunequipment,
suchaspumpsandlights.Anycircuitcanbeprogrammedtoswitchonandoffataspecictimeoneveryor
anyspecicdayoftheweek.Thenumberofprogramsthatcanbecreatedforcircuitsareasfollows:
• Up to four (4) programs can be created for all circuits combined.
• Onecircuitcanhaveuptoamaximumoffour(4)programs(1/4).Programsthatcanusedbycircuitsfor
a total of four (4) programs.
Using the Schedules menu
UsetheSchedulesmenufeaturestoprogramoperatingschedulesforthepool,spaandauxiliarycircuits:
MENUsSCHEDULES wSPA
Choose the circuit to program
Up/Down button: Selectthegenericcircuitnametoprogram:Spa,Pool,Aux1-3,
Feature1-2.
Thecurrentnumberofprogramsforeachcircuitisdisplayedoppositethecircuit
name.Acircuitcanhaveupto4programs(1/4).Threeadditionalprogramscanbe
assignedtoanothercircuitorthreeseparatecircuitsforamaximumofseven(7)
programs.
Create a new program
Thecurrentnumberofprogramsforeachcircuitisindicatedoppositetothecircuit
name.0/0indicatesnoprogramsassignedtothiscircuit.
Right button: Tomovetothe“Mode”selection.
Up/Down button: SelectNewtocreateanewprogram.Use“None”whenacircuit
hasexistingprogramsandyouwishtoexitthe“Mode”selectionswithoutmodifying
theexistingprograms.
Choose the type (Mode) of program to run
Afterselecting“New”thecurrentprogramnumber(1/1)forthiscircuitisdisplayed.
Right button: Tomovetothe“Mode”selections.
Up/Down button: Choosetheprogramtorun:Schedule, Egg Timer, New, Delete,
and None.Ifthereareexistingprogramsassignedtothiscircuit,usethesebuttonsto
viewandselecttheexistingprogramsettings.
Mode Selection:
Schedule:Setstart,stoptimesandtheday(s)oftheweektoautomaticallyswitch
pool/spacircuitsonoroff.Defaultruntimeforthe“Schedule”featureis8:00AMto
5:00PM.Ifyouprogramthestartandstoptimesthesamethescheduleiswillrunfor
24hours.
Egg Timer: Aonetimeprogramthatswitchesonafunctionataspecictime,and
countsdownthepresettimetotheswitchoffthefunction. Afterthe“EggTimer”
schedulehasnished,thesystemcanbeoperatedinmanualmode.The“DON’T
STOP”optionallowsacircuittoruncontinuouslyuntilitsswitchedoffmanually.
New:presstheRight buttontocreateanewprogram.
Delete:SelecttheprogramandpresstheRight buttontodeleteit.
None:PresstheRight buttontoexitthe“Mode”selectionswithoutmodifyingthe
program.
SPA 0/0
Mode: None

SPA 0
POOL 0
AUX 1 0
AUX 2 0



SPA 1/1
Mode: Egg Timer
Timer: 12:00


SPA 1/1
Mode: Delete


SPA 1/1
Mode: None


SPA 0/0
Mode: New


SPA 1/1
Mode: New


SPA 1/1
Mode: Schedule
08:00A - 05:00P
smtwtfs


