44
EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
Settings Menu: Circuit Functions
Assigning Circuit Functions
Fromthe“CircuitFunctions”menuyoucanassignspeciallogictothecleanerpump,spaspillway,lightsand
MagicStream
®
Laminarcircuits.Forexample,whensettingupanautomaticpoolcleanerpump,youwould
assignthecircuitfunction“MASTERCLEANER.”Withthis“Cleaner”logicthecleanerpumpwouldforce
thelterpumpon,andthecleanerpumpwouldstartafteradelayofveminutes.Thecleanerpumpwould
automaticallyshutoffwheneverthespaand/orsolarisswitchedon.
Freeze Protection
Freezeprotectionswitchesonacircuitiftheoutsideairtemperaturesensordetectsthetemperatureisgetting
closetofreezing(below35°F(40°C)).Thesystemwillswitchonallcircuitsthathavebeenassignedfreeze
protection,andrunsthecircuitsfor15minutestostopthepipesfromfreezing.Thisisespeciallyimportant
ifthereisapoolandspacombination.Iffreezeprotectionissettoboththespaandpoolcircuits,thelter
pumpswitchesonandthepoolandspavalvesalternateevery15minutestokeepthewatermovinginboth
thepoolandspa.Thisprocesscontinuesuntilthefreezeconditionisover.
Circuit Functions
Toassignacircuitfunctionandfreezeprotection:
MENUsSETTINGSsCIRCUIT FUNC.wCIRCUIT/FUNC.
Up/Down buttons: Choosethecircuitname(displayedonthesecondline).The
genericcircuitsnamesare:SPA [MASTER SPA - Freeze protection on by default],
POOL [MASTER POOL - Freeze protection on by default], AUX 1-3 FEATURE
1-2.
Right button: Movetothe“CircuitFunction”settingtoselectthecircuitfunctionfor
theselectcircuitnamedisplayedonthelineabove.
Up/Down buttons: Selectthecircuitfunction.Thisisthecircuitthatyouwishto
assignthefunctionlogicto.For a complete list of preset circuit functions, see
“Preset Circuit Functions,” on page 42.
Right button: MovetoFreezeProtectionsetting.
Up/Down buttons: SelectYesorNotoassignfreezeprotectiontothiscircuit.If“Yes”
isselected,thecircuitwillswitchoniftheairtemperaturedropsto35°F.
Note: for the POOL circuit the filter pump will have freeze protection. For the SPA
circuit the filter pump will run and the pool/spa valves will switch between pool
and spa at 15 minutes intervals throughout the freeze condition. For the MASTER
CLEANER circuit freeze protection is generally not needed for pool cleaner pumps
since they get water flow from the filter pump. Just make sure that POOL has freeze
protection.
PresstheMenubuttontosavethesettingsandtoreturntotheSettingsmenu
options.Pressthebuttonagaintoreturntothemainmenuoptionsorpressagainto
returntothemainscreen.
Circuit/Func.:
[SPA ]
[Master Spa ]
Freeze: Yes


Circuit/Func.:
[AUX 1 ]
[LIGHT ]
Freeze: No


