EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
Heat Menu
Usetheheatmenusettingstospecifythesetpointtemperatureandselecttheheatsourceforthepool
andspawater.Thewaterwillbegintoheatwhenevertheheaterismanuallyswitchedon,(bypressingthe
Valves(V)button(ontheOutdoorControlPanel)orthe“Pool”or“Spa”buttonontheIndoorControlPanel
andWirelessController),eveniftheheaterissettooff.TheEasyTouch
®
PL4/PSL4ControlSystemallows
forsolarandconventionalheaters.Thesystemwillusetheheatingsourcethatisselected.Theheatsource
selectionsare:
• OFF -Noheatingeventhoughpumpandothercircuitsmaybeoperating.
• HEATER - Gasheateronly.UsetheHeaterbuttontoautomaticallyswitchtheheateronwhich
controlstheoutputbetweena“forcedoff”stateandanormal,automaticthermostaticcontrol
operatingstate.Theheaterwillcontinueheatingthewateruntiltheheater’scurrenthighestsetpoint
temperaturetriggerstheheatersensor(approximately104°F(40°C).NotethattheHeaterbuttonon
thecontrolpaneldoesnotactivatethepump.Donotactivatetheheaterwithoutrunningthepump.
Theheaterwillnotrunifwaterowisnotdetected.
• SOLAR ONLY-Solarheatingsystemtobetheonlyheatsource.Inordertodisplay“SolarPref.”on
themainscreen,youmustrstenablesolarinthe“Solar”menu(seepage47).
• SOLAR PREF. (Solar Preferred)-Solarandgasheatingsystemsareinstalled,andyouwanttouse
solarheatingonlywhenitismosteffective.Inordertodisplay“SolarPref.”onthemainscreen,you
mustrstenablesolarinthe“Solar”menu.Tosetthespatemperatureandselecttheheatsource:
Pool Temp/Src
Tosetthepooltemperatureandselecttheheatsource:
MENUsHEAT
Right button: Selectpooltemperatureandheateroptions.
Up/Down button: Setthepooltemperaturefrom40°Fto104°F(4°C-40°C).
Right or Left button: MovetoHeateroption.
Up/Down: SetHeateroption:Off, Heater, Solar, orSolar Preferred.
PresstheMenubuttontosavethesettingsandtoreturntothepreviousmenuor
pressthebuttonagaintoreturntothemainscreen.
Spa Temp/Src
Tosetthespatemperatureandselecttheheatsource:
Right button: Selectspatemperatureandheateroptions.
Up/Down button: Setthespatemperaturefrom40°Fto104°F(4°C-40°C).
Right or Left button: MovetoHeateroption.
Up/Down: SetHeateroption:Off, Heater, Solar, orSolar Preferred.
PresstheMenubuttontosavethesettingsandtoreturntotheHeatmenuorpress
thebuttonagaintoreturntothemainscreen.
Note: For the EasyTouch PL4 Control System single body system, “Pool” and “Spa” modes are Lo- Temp
(Pool) and Hi-Temp (Spa) temperature controls. For more information, see “Hi-Temp/Lo-Temp Controls for
Single Body Systems,” on page 42.
POOL
Temp: 72° F
Heat: Off


POOL Temp/Src
SPA Temp/Src



SPA
Temp: 85° F
Heat: Off


POOL Temp/Src
SPA Temp/Src



