EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide

Chlorinator
Salt Level:3200ppm
Status:
[OK-NO ERRORS]



Water Temperature
75° F
Diagnostics Menu: Chlorinator
DisplaysthecurrentIntelliChlor
®
SaltChlorineGeneratorsystemstatus.Formoreinformation,refer
totheIntelliChlorSaltChlorineGeneratorUser’sGuide(P/N520589).
MENUsDIAGNOSTICSsCHLORINATOR
Menu: PressthisbuttontoreturntotheSettingsmenuoptions.Pressthe
buttonagaintoreturntothemainmenuoptionsorpressagaintoreturnto
themainscreen.
SALT LEVEL: Displaysthecurrentsaltlevel.Valuesfrom0to12750ppmin
50ppmincrements.
IntelliChlorStatusmessages:
SUPER CHLORINATE: IntelliChlorisin“SuperChlorinationmode(seepage
35fordetails)
COM LINK ERROR: CheckcablefromIntelliChlortoEasyTouchPL4/PSL4
ControlSystemmiancircuitboard.
Check FLOW/PCB:CheckIntelliChlorelectrolyticcellcontroller.Referto
IntelliChlorUser’sGuidetroubleshootinginformation.
LOW SALT: Addsalttopoolwater.Thewatersaltlevelisbetween2500
ppmand2900ppm.TheIntelliChlorwillcontinuetoproducechlorineata
reducedlevel.
VERY LOW SALT: Notenoughsaltinpool.Thewatersaltlevelhasfallen
below2500partspermillion(ppm).IntelliChlorwillnotproducechlorineuntil
additionalsaltisaddedmanually.
HIGH CURRENT: CheckIntelliChlorelectrolyticcellcontroller.Referto
IntelliChlorUser’sGuidetroubleshootinginformation..
CLEAN CELL!!:Cellhascalciumbuildupandrequirescleaning.Referto
IntelliChlorUser’sGuideforcleaninginstructions.
LOW VOLTAGE: CheckIntelliChlorelectrolyticcellcontroller.Referto
IntelliChlorUser’sGuidetroubleshootinginformation.
OK - NO ERRORS: IntelliChlorisinnormaloperatingmode.
Diagnostics Menu: Water Temp
Displaysthecurrentwatertemperatureforthepoolandspa.
MENUsDIAGNOSTICSsWATER TEMP
PresstheMenubuttontoreturntotheSettingsmenuoptions.Pressthe
buttonagaintoreturntothemainmenuoptionsorpressagaintoreturnto
themainscreen.
Diagnostics Menu: Solar Temp
Displaysthecurrentsolartemperature.
MENUsDIAGNOSTICSsSOLAR TEMP
PresstheMenubuttontoreturntotheSettingsmenuoptions.Pressthe
buttonagaintoreturntothemainmenuoptionsorpressagaintoreturnto
themainscreen.


Solar Temperature
85° F
