Pentair EASYTOUCH PL4 User Manual

EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
7
AUTO HEATER
SPA 85°F / 100°F
AIR 70°F FRZ
MON 09:30 AM
EasyTouch
®
PL4/PSL4 Control System Indoor Control Panel (Optional)
TheEasyTouchPL4/PSL4ControlSystemIndoorControlPanelallowsyoutocontrolthepoolandspadaily
operationsfromaroundyourpoolareaorinsideyourhome.Usethe“P”(Pool)and“Spa”(Pool)buttonsto
heatandlteryourpoolandspa.TheindoorcontrolpanelconnectstotheEasyTouchPL4/PSL4Control
SystemmaincircuitboardlocatedinthePowerCenter.
EasyTouchPL4/PSL4ControlSystemIndoorControlPanel
Spa (Hi-Temp) Button:
Switchesthelterpump
on,rotatesvalveactuator
(toisolatespawaterfrom
poolwater),andswitches
theheateron.Hi-Temp
(singlebodysystem)sets
thehightemperature
settingsforthespa.
Pool (Lo-Temp) Button:
Switchesthelterpump
on,rotatesvalve
actuator(toisolatepool
waterfromspawater),
andswitchesheateron.
Lo-Temp(singlebody
system)setsthelow
temperature
settingsforthepool.
SetTemperaturebuttons,
seepage3.
CircuitLED.
Circuitname
label.
Three(3)userdened
auxiliarycircuits.But-
tonsswitchtheas-
signedcircuitfunction
on/off.
(Defaulttimeisa12
hourtime-out).
(Leftarrowbutton)
Lowersettemperature
(Rightarrowbutton)
Raisesettemperature
AUTO (Automatic): Thesystemisinnormaloperatingmode.
Scheduledprogramswillrunautomatically.SERVICEorTIMEOUTmodearedisplayedwhen
thesystemisbeingserviced.ThesemodesareactivatedfromtheOutdoorControlPanel.
HEATER:Heaterisswitchedon.DisplayswhenthePool(P)orSpabuttonispressed.For
pooloperationstheheatsourcemustbeenabledintheHeatmenu(seepage30).Displays
“Solar”or“SolarPrf”ifsolarisenabled.Theheaterisactivewhenthesettemperatureis
higherthanthewatertemperature.Theheaterwillswitchoffwhenthewatertemperaturerises
abovethesettemperature.
SPA (Hi-T) or POOL (LO-T) :DisplayswhentheSpa/HI-TorPool/LO-Tbuttonispressedto
rotatevalveactuatorsandactivatethelterpumpandheater.Thislineonthescreenisblank
whennospaorpoolfunctionisactive.Note:DependingonthecongurationofthePL4/PLS4
ControlSystem,thescreendisplaysSPA(sharedequipment-EasyTouchPSL4Control
System),HI-T(singlebodyofwater-EasyTouchPL4ControlSystem).
system),POOL(sharedequipment),LO-T(singlebodyofwatersystem).
85° F / 100° F:Displaystheactualspaorpoolwatertemperature
(85°F)andthesetpointtemperature(100°F)assetintheHeatermenu.Degreeunitsare
displayedineitherFahrenheitorCelsius.
AIR:Displaystheactualoutsideairtemperature(70°F)asreadbytheairsensorlocatednear
thePL4/PLS4ControlSystemPowerCenter.DegreeunitsaredisplayedineitherFahrenheit
orCelsius(seepage49).
FRZ:Displayswhenfreezeprotectionisactive.Toprotectpoolsystemequipment,freeze
protectionmustbeenabledforthelterpumpcircuit.Iftheoutsideairtemperaturesensor
detectsthetemperatureisgettingclosetofreezingpoint(below36°F(2°C)),thefreeze
protectionfeatureswitchesonthelterpumpcircuittocirculatewaterthroughthesystem.For
moreinformation,seepage44.
DEL:Displayswhen“DelayCancel”isactive.Formoreinformation,seepage31.
Date and Time:DisplaysthePL4/PLS4ControlSystemdayandtimeasspeciedinthe
“Clock”menusetting(seepage34).
