EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
  17
SPA 0/0
Mode: None (New)

SPA 0
POOL 0
AUX 1 0
AUX 2 0



SPA 1/1
Mode: Schedule
08:00A - 05:00P
s
mtwtfs


_ _ _
Quick Start - Spa and Pool Operations (Shared Equipment) Continued
MENUsSCHEDULESwSPA (POOL)
Tocreateascheduleforyourspaorpool:
Right button: SelecttheSpaorPoolcircuit.Youcanalsoselectanyoftheavailable
circuits.Thegenericcircuitnamesare:Spa,Pool,Aux1-3,Feature1-2.
Right button: SelectMode ifthereareexistingprograms.Skipthissteptocreateanew
program.
Up/Down button: SelectNewtocreateanewprogram.
Right button: Tocreateanewprogramandenterthe“Mode”settings.
Up/Down button: 1/1indicatesthatthiscircuithasoneprogram.Ifthereareexisting
programsassignedtothiscircuit,usethesebuttonstoviewandselecttheexisting
programsettings.
Right button: Toselectthe“Schedule”settings.
Right button: Movetostartandstoptimesettings.
Up/Down and Right buttons: Setstartandstophour(A/P),minutes.
TheA(AM)andP(PM)timeissetwhensettingthestartandstophour.
Right button: Movetodaysoftheweektoruntheprogram.
Right and Up/Down buttons: Bydefaulttheprogramissettorunallthedaysofthe
week.Ifyouwishtoeditwhichdaystoruntheprogram,selectthedayoftheweek,then
presstheUp/Down buttontoremovethebarfromthetopoftheletter.Abarontopofthe
letterindicatesthedayselectedtoruntheprogram.
PresstheMenu buttontosavethesettingsandtoreturntotheSchedulesmenuoptions.
Pressthebuttonagaintoreturntothemainmenuoptionsorpressagaintoreturntothe
mainscreen.
