Pentax K-5 User Manual

19
Before Using Your Camera
1
Names and Functions of Working
Parts
* In the first illustration, the camera is shown with the Hot shoe cover FK
removed.
* In the second illustration, the camera is shown with the Hot shoe cover F
K and
the Eyecup F
R removed.
Tripod socket
Battery cover
Self-timer lamp
/Remote control receiver
AF coupler
Mirror
Lens unlock button
Lens information
contacts
Card cover
Battery cover
unlock knob
Battery grip contacts
Strap lug
Hot shoe
Lens mount index
Card access
lamp
Built-in flash
PC/AV terminal
DC input terminal
LCD Panel
Terminal cover
Cable release
terminal
Self-timer lamp/
Remote control
receiver
X-sync socket
Diopter adjustment
lever
mini HDMI terminal
(Type C)
Microphone terminal
Strap lug
AF assist light
Microphone
Speaker
Viewfinder
Image plane
indicator
Monitor

Pentax K-5 Specifications

General

Megapixel	16.93 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	No
Image sensor size	- \
Maximum image resolution	4928 x 3264 pixels
Digital zoom	- x
Focal length range	- mm
Interface	USB 2.0
Digital SLR	Yes
Power supply type	D-LI109
Aperture range (F-F)	-
Camera shutter speed	30 - 1/8000 s
Effective sensor resolution	921000 pixels
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
ISO sensitivity	100, 1600, Auto
Light exposure modes	aperture priority AE, auto, manual, shutter priority AE
Flash modes	Red-eye reduction, Slow synchronization
Internal memory	- MB
Compatible memory cards	SD, SDHC
Motion JPEG frame rate	25 fps
Maximum video resolution	1920 x 1080 pixels
Display diagonal	3 \
Magnification	32 x
USB version	2.0
Scene modes	Backlight, Portrait, Landscape (scenery)
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Manual, Shade, Tungsten
Product color	Black
Battery life (max)	7 h
Battery life (CIPA standard)	980 shots
Bundled software	PENTAX Digital Camera Utility 4

Weight and Dimensions

Depth	73 mm
Width	131 mm
Height	97 mm
Weight	740 g
