298
Changing Additional Settings
9
You can adjust the color of the monitor.
1
Select [LCD Color Tuning] in the [R Set-up 2] menu and
press the four-way controller (5).
The [LCD Color Tuning] screen appears.
2
Adjust the color.
Seven levels (225 patterns) are available
on the G-M and B-A axes.
Available operations
3
Press the 4 button.
4
Press the 3 button.
The screen that was displayed before selecting the menu appears again.
Adjusting the Color of the Monitor
Four-way controller (23) Adjusts the tone of the colors between green (G)
and magenta (M).
Four-way controller (45) Adjusts the tone of the colors between blue (B)
and amber (A).
| button Resets the adjustment value.
Front e-dial (R) Displays a saved image in the background so
you can adjust the color while viewing the
image. This is useful for matching the color of
the monitor with that of a computer.
Cancel
LCD Color Tuning
MENU
GG
BBA
A
MM
±0 ±0
±0
OK
OK
To Next Page
