Before Using Your Camera
1
35
The following information appears in the viewfinder.
Viewfinder
1 AF frame (p.61)
2 Spot metering frame (p.118)
3 AF point (p.127)
4 Flash indicator (p.77)
Lit: when the flash is available.
Blinks: when the flash is recommended but not set or is being charged.
5 Focus Mode (p.132)
Appears when the focus mode is set to \.
6 Shutter speed
Underlined when the shutter speed can be adjusted.
Displays a countdown of processing time when the Noise Reduction
function is activated. (p.98)
7 Aperture value
Underlined when the aperture value can be adjusted.
[nr] blinks when the Noise Reduction function is activated. (p.98)
8 Focus indicator (p.72)
Lit: when the subject is focused.
Blinks: when the subject is not in focus.
9 EV bar
Displays the EV compensation values or difference between the
appropriate and current exposure values when the exposure mode is set to
a or M. (p.119)
Displays the camera angle when [Electronic Level] is O (On). (p.38)
1
4
19
181716151413
61011
12
2
1
3
5 7 8 9
To Next Page
