1.5.2 Dielectric System:
The service unit includes a re-circulating dielectric fluid filtration and reconditioning
system. This system requires regular service, as detailed in section 3.
1.5.3 Touch-Screen Display:
The Touch-Screen Display (TSD) provides an interface through which the user can
select different fastener types to remove (as described in Section 2) and carry out
maintenance functions (as described in Section 3). The TSD also displays status
information including:
• Current fastener setting
• Cut time for last cut
• Current system status or error messages
TSD operation is listed in more detail in Section 2.
