CAUTION
The system is optimized for no greater than 30’ maximum distance between Cabinet and
Hand-tool. Use of an umbilical Extension with the long-cabled hand-tools (CP1-CED-310
& 320) or usage of multiple extension umbilical’s with short cable hand-tools will
significantly negatively impact cutting performance and will invalidate warranty and
regulatory safety compliance.
To install the Umbilical Extension the procedure is as follows:
1. Disconnect the hand-tool from the back of the Power Supply Cabinet by
rotating the twist-lock bezel in a counter-clockwise direction, then depressing
the barrel around the push-to-connect fluid fittings and pulling out the fluid
hoses.
2. Transfer the fluid hoses from the hand-tool umbilical to the female end of
the extension umbilical by depressing the barrel around the push-to-connect
fittings.
3. Connect the umbilical extension to the rear of the Power Supply Cabinet by
inserting the power connector and rotating the bezel clockwise firmly until a
click is felt. The power connector can only be inserted one way – if it will not
insert then rotate it until insertion is possible. Re-insert the fluid hoses
between the Power Supply Cabinet and the extension umbilical.
4. Connect the hand-tool to the male end of the umbilical extension by lining
up the electrical connection and the pre-installed fluid pipes and rotating the
bezel to close. The fluid pipes are two different sizes so that they can only
be inserted into the correct couplings as the bezel is turned. Bleed the water
line as described in Section 3.7.
5. Removal of the Umbilical Cable is the reverse of installation.
2.10 Keys to Successful Operation of the E-Drill:
1. Select the right fastener setting on the Touch-Screen Display.
2. Ensure you are using the correct E-Drill Adapter and Electrode for the
fastener you wish to remove.
3. Lightly locate the hand-tool concentric with the fastener and co-axial with it.
4. Using thumb and forefinger press the E-Drill lightly down over the fastener in
order to a) depress the central ground pin (CG hand-tool only), and b)
minimize any water leaks which may occur during cutting.
