Perfect Point E-Drill - Cp1-Sy

15192 Triton Lane
Huntington Beach, CA 92649
Office Tel: 714-892-3400
Hotline Tel: 714-891-6533
www.ppedm.com
User Guide
Document No.
61-101
Revision:
107
Date:
10/18/2018
This document is the property of PPedm Corp. and contains proprietary and/or patented information and may not be reproduced in
part or in whole without the express written permission of the company. Perfect Point logo, Perfect Point
TM
and E-Drill
®
are
trademarks of PPedm, Corp. US and worldwide patents pending.
Page 22 of 76
Connection
Panel
Dielectric
Filter
Assembly
Lock-Bolt
Sediment
Bowl
Particulate
Filter Bowl
Mobile Service Unit - Rear View
(CP1-SY-151 has a separate tool-cart instead of the toolbox)
