5.4.3 BHL Adapter and Guide Assembly:
The BHL Adapter and Guide Assembly is installed on the end of the E-Drill
for the selected fastener removal application. BHL Adapters are supplied in
both Bayonet and Tri Wing E-Drill attachment configurations for EG and CG
E-Drill use.
Note: See Section 1.4 Guide Extraction for Guide replacement instructions.
Button Head Adapter Assembly with Electrode Guide Installed
