PG DRIVES TECHNOLOGY I-DRIVE TECHNICAL MANUAL – WARNING SUMMARY
2.34 Current Foldback Temperature
The value of Current Foldback Temperature should never be set higher than 80°C. PGDT accepts
no liability for losses of any kind arising from failure to comply with this condition.
2.35 Motor Compensation
Motor Compensation should never exceed 60%.
The machine manufacturer is responsible for ensuring that the controller is matched to the motor
resistance. Failure to do this may result in poor control characteristics, which in extreme
instances can make a machine uncontrollable and potentially unsafe. PGDT accepts no liability for
losses of any kind arising from failure to comply with this condition.
The machine manufacturer is responsible for always ensuring that any replacement motors are
fully compatible with the originals that the controller was designed to match. Failure to do this
may result in poor control characteristics, which in extreme instances can make a machine
uncontrollable and potentially unsafe. PGDT accepts no liability for losses of any kind arising
from failure to comply with this condition.
2.36 Pull-Away Delay
PGDT recommend a value of 300ms for the Pull-Away Delay as an optimum setting. This should
be verified for each application by the machine manufacturer.
2.37 Belly Button Time
The machine manufacturer is responsible for ensuring that the wiring of the Belly Button switch
and the programming of the Belly Button parameters are suitable for the intended application.
PGDT accepts no liability for losses of any kind arising from the incorrect wiring or programming
of the Belly Button function.
2.38 Safety Fences
PGDT accepts no liability for losses of any kind if the machine manufacturer does not specify
appropriate safety fence values for a particular application.
SK76977-07 111
