PG DRIVES TECHNOLOGY I-DRIVE TECHNICAL MANUAL – PROGRAMMING
1 Introduction
This chapter gives an overview of the programmable parameters within the i-Drive Controller. The i-Drive can be programmed
with a hand-held SP1, DTT or PGDT’s Industrial PC Programmer.
This chapter does not give details of how to make adjustments; for these details please refer to the relevant documentation for
the programmer you are using.
Programming should only be conducted by electronic service professionals with in-depth
knowledge of PGDT controllers. Incorrect programming could result in an unsafe set-up of a
machine for a user. PGDT accepts no liability for losses of any kind arising from failure to comply
with this condition.
1.1 SP1a & DTT
The SP1a and DTT handheld programmers are intended to give dealers and service engineers access to basic programmable
parameters and diagnostic information. The standard functions are:
Acceleration
Deceleration
Forward Speed
Reverse Speed
Throttle Invert
Sleep Timer
Read System Log
Read Timer
For details of how to use the SP1a or DTT, refer to the relevant documentation.
1.2 PC Programmer
There are two versions of the PC Programmer.
iPCPa Dealer level access, equivalent to SP1a and DTT.
iPCPb OEM level access, suitable for the machine manufacturer and their service engineers.
The OEM level access variant also includes a suite of functions, which make it suitable for ‘end-of-line’ programming.
For details of how to use these programming packages with the i-Drive, refer to the documentation supplied with the software.
1.3 Parameters
The i-Drive parameters are separated into workable groups for easy referencing.
The groups and their sections are:
Speeds – Section 2
Forward Acceleration Forward Deceleration
Reverse Acceleration Reverse Deceleration
Max. Forward Speed Min. Forward Speed
Max. Reverse Speed Min. Reverse Speed
Speed Limit Pot. Enabled
SK76977-07 63
