PG DRIVES TECHNOLOGY I-DRIVE TECHNICAL MANUAL – TRUCHARGE MODULE
4 Wiring
The machine manufacturer is responsible for establishing the suitability of the particular wiring arrangement used on the
machine. PG Drives Technology can make general recommendations for wiring to TruCharge Modules, but PG Drives Technology
accepts no responsibility for the wiring arrangement used.
4.1 Wire Gauge
The minimum recommended wire size is 0.22mm
2
for all connections.
4.2 Connectors
4.2.1 Surface Mount Variant
The TruCharge Module is fitted with a Molex ‘Mini-fit Jr’ 4 way connector.
See
www.molex.com for your local distributor.
Part Numbers are as follows:
Molex ‘Mini-Fit-Jr.’ 4 socket receptacle: 39-01-2040
PG Drives Technology TruCharge Display Cable.
PGDT Part number: SA76199
Only use the PG Drives Technology TruCharge Display Cable number SA76199 supplied with kit
D50826.
Hand tools for crimping and extraction are available from Molex. The references are as below.
Molex ‘Mini-Fit-Jr.’ Crimp tool: 69008-0724
Molex ‘Mini-Fit-Jr.’ Extraction tool: 11-03-0044
Only use the exact tools specified.
4.2.2 Inset Variant
The TruCharge Module is fitted with a 3 way AMP CT series connector, part number 175487-3. The mating crimps and connector
housing have Amp part numbers 179227-1 and 179228-3 respectively. Only these parts should be used.
There is also a solder/ring tag point for an Electro-Static Discharge (ESD) drain path wire.
SK76977-07 99
