I-DRIVE TECHNICAL MANUAL – DIAGNOSTICS PG DRIVES TECHNOLOGY
2.6.2 Inhibit 2 Active
This occurs when the controller detects that the Inhibit 2 input is active, Inhibit 2 Speed has been set to ‘0’ and Inhibit 2 Operation
has been set to ‘Latched’. This input is located on pin 14 of the 14-way Tiller Connector. Check the state of the input, Inhibit 2
programming, connectors and relevant wiring to the i-Drive.
If the trip is still present after the state of the input, programming, connectors and wiring have been checked, the controller may
be defective. Refer to
Section 3.
2.6.3 Blink – Sleep Mode
This occurs when the controller enters Sleep Mode. Turn the controller off and then on to awake the system. To disable Sleep
Mode, program the parameter Sleep Timer to 0 minutes.
2.7 Trip Type 7 – Throttle Trip
2.7.1 Parallel Speed Pot. Wiper Error
This occurs when the controller detects that the Parallel Speed Limit Potentiometer Wiper is open circuit or has been shorted to
one of the throttle references. The Parallel Speed Limit Potentiometer Wiper input is located on pin 9 of the 14-way Tiller
Connector. If this error occurs, the controller will allow drive to continue but at the minimum programmed speed. Check the
parallel speed potentiometer, connections and relevant wiring to the i-Drive.
If the trip is still present after the potentiometer, connectors and wiring have been checked, the controller may be defective.
Refer to
Section 3.
2.7.2 Throttle Reference Error
This occurs when the controller detects an error with one of the throttle references, either high or low. The throttle references are
located on pins 2 and 8 of the 14-way Tiller Connector, respectively. Check the throttle potentiometer, connectors and relevant
wiring to the i-Drive.
If the trip is still present after the potentiometer, connectors and wiring have been checked, the controller may be defective.
Refer to
Section 3.
2.7.3 Series Speed Pot. Wiper Error
This occurs when the controller detects that the Series Speed Limit Potentiometer Wiper is shorted to one of the throttle references,
either high or low. The Series Speed Limit Potentiometer Wiper input is located on pin 1 of the 14-way Tiller Connector. The trip is
only applicable if an ISO-test resistor is fitted and programmed correctly. Check the throttle potentiometer, programming,
connectors and relevant wiring to the i-Drive.
If the trip is still present after the potentiometer, programming, connectors and wiring have been checked, the controller may be
defective.
Section 3.
2.7.4 Throttle Displaced At Start-Up
This occurs when the controller detects that the Throttle Potentiometer has been displaced at start-up and the parameter Throttle
Operated At Power-Up has been set to ‘Trip’. Check that the operator is not deflecting the throttle at power-up, the throttle
potentiometer, connectors and relevant wiring to the i-Drive.
If the trip is still present after the operator use, potentiometer, connectors and wiring have been checked, the controller may be
defective.
Section 3.
2.7.5 Belly Button Active At Start-Up
This occurs when the controller detects that the Belly Button Switch has been operated at power-up. The Belly Button Input is
located on pin 9 of the 14-way Tiller Connector. Check the Belly Button Switch, connectors and relevant wiring to the i-Drive.
If the trip is still present after the switch, connectors and wiring have been checked, the controller may be defective. Refer to
Section 3.
SK76977-07 90
