I-DRIVE TECHNICAL MANUAL – DIAGNOSTICS PG DRIVES TECHNOLOGY
2 Trip Types And Possible Causes
Once the trip type has been established, refer to the relevant section below for further information.
Trip Code Trip Type Description & Reference
0300 - Throttle Trip. Refer to Section 2.7.1
0815 7 Throttle Trip. Refer to Section 2.7.2
0A00 6 Sleep Mode. Refer to Section 2.6.3
0E07 7 Throttle Trip. Refer to Section 2.7.3
1500 9 Short Circuit In Solenoid Brake. Refer to Section 2.9.1
1502 9 Open Circuit In Solenoid Brake. Refer to Section 2.9.2
1600 10 High Battery Voltage. Refer to Section 2.10.1
1601 10 Very High Battery Voltage. Refer to Section 2.10.2
1E08 6* Inhibit 1 Active. Refer to Section 2.6.1
1E09 6* Inhibit 2 Active. Refer to Section 2.6.2
2C00 1 Low Battery Voltage. Refer to Section 2.1.1
2C01 1 Very Low Battery Voltage. Refer to Section 2.1.2
2F01 7* Throttle Displaced At Start-Up. Refer to Section 2.7.4
3B01 2 Motor Open Circuit. Refer to Section 2.2
3D02 3 Motor Shorted To Battery Positive. Refer to Section 2.3.1
3D03 3 Motor Shorted To Battery Negative. Refer to Section 2.3.2
4401 - Record Of Possible Control Fault. Refer to Section 2.8.2
5300 8 Programmable Setting Changed. Refer to Section 2.11
7901 7 Belly Button Active At Start-Up. Refer to Section 2.7.5
All Other Codes 8 Possible Controller Fault. Refer to Section 2.8.1
*Dependant on programming.
Trip Types 4 and 5 are not used for i-Drive.
SK76977-07 88
