PG DRIVES TECHNOLOGY I-DRIVE TECHNICAL MANUAL – OPERATION
1 Introduction
The relevant contents of this chapter should be included in the machine operating guide. Further copies are available from PGDT
in either written or disk (Microsoft Word) format. Copies should not be made without the express permission of PG Drives
Technology.
Operation of the i-Drive controller is simple and easy to understand. The controller incorporates state-of-the-art electronics, the
result of many years of research, to provide you with ease of use and a very high level of safety. In common with other electronic
equipment, correct handling and operation of the unit will ensure maximum reliability.
This chapter covers all types of operation. It is the responsibility of the machine manufacturer to ensure that only the relevant
sections of this chapter are included in the i-Drive’s operating manual.
Please read this chapter carefully - it will help you to keep your machine reliable and safe.
2 General
2.1 Handling
Avoid knocking your controller and especially the connectors. Be careful not to strike obstacles with the controller. Never drop the
controller.
When transporting your machine, make sure that the controller is well protected. Avoid damage to cables.
2.2 Operating Conditions
Your controller uses industrial-grade components throughout, ensuring reliable operation in a wide range of conditions. However,
you will improve the reliability of the controller if you keep exposure to extreme conditions to a minimum.
Do not expose your controller or its components to damp for prolonged periods.
3 Controls
Depending on the specification of the machine to which the i-Drive is fitted, some or all of the following controls will be used.
3.1 On/Off Switch
The On/Off switch applies power to the controller electronics, which in turn supplies power to the machine’s motor. Do not use the
On/Off switch to stop the machine unless there is an emergency. (If you do, you may shorten the life of the machine drive
components).
Some machines may have a keyswitch in addition to the normal On/Off switch; the function of the
keyswitch is the same as the On/Off switch.
SK76977-07 11
