Table 3 to Table 8 provide an overview of the pinout of the different
phyFLEX-Connectors X1, X2, and X3 with signal names and
descriptions specific to the phyFLEX-i.MX 6. It also provides the
appropriate voltage domain, signal type (ST) and a functional
grouping of the signals. The signal type includes also information
about the signal
1
. A description of the signal types can be found in
Table 1.
The Freescale Semiconductor i.MX 6 is a multi-voltage operated
microcontroller and as such special attention should be paid to the
interface voltage levels to avoid unintentional damage to the
microcontroller and other on-board components. Please refer to the
Freescale Semiconductor i.MX 6 Reference Manual for details on the
functions and features of controller signals and port pins.
1
: The specified direction indicated refers to the standard phyFLEX use of the pin.
