Phytec phyFLEX-i.MX 6 - CMIC Boot Configuration Signals

System Configuration and Booting
 PHYTEC Messtechnik GmbH 2013 L-773e_2
37
Boot
mode
Description BOOT_MODE
[1:0]
BCFG1[7:4] BCFG2[1] BCFG4[2]
0 NAND 0b10 0b1000
depends
on NAND
size
0bZ
1 SPI 0b10 0b0011 0bZ 0bZ
2 SPI 0b10 0b0011 0bZ 0bZ
3 SD0 0b10 0b010Z 0bZ 0bZ
4 USB OTG 0b01 0bZZZZ 0bZ 0bZ
5 SATA 0b10 0b0010 0bZ 0bZ
6 USB OTG 0b01 0bZZZZ 0bZ 0bZ
7 eFUSE 0b00 0bZZZZ 0bZ 0bZ
Table 13: Boot Configuration Signals generated by the CMIC
