Phytec phyFLEX-i.MX 6 - Table 9: Jumper Settings

phyFLEX
®
-i.MX 6 [PFL-A-XL1-xxx
26  PHYTEC Messtechnik GmbH 2013 L-773e_2
The jumpers (J = solder jumper) have the following functions:
Jumper Description Type Chapter
J3
J3 connects the write protect input of the on board
EEPROM with GND. If this jumper is not
populated, the EEPROM is write protected.
0R
(0402)
6.3
closed EEPROM is not write protected
open EEPROM is write protected. The protection can be
changed by the EEPROM_WP signal
J5-J8,
J10-J21,
J24,J28-
J30
These jumpers are connected to the boot
configuration inputs of the i.MX 6. They can be
used to change the boot settings according to the
i.MX 6 datasheet.
Please refer to the i.MX 6 data sheet for more
detailed information.
10 kΩ
(0402)
5
J9 J9 selects rising, or falling edge strobe for the
LVDS Deserializer at U12 used for the camera
connectivity of the phyFLEX-i.MX 6 (CSI1)
0 Ω
(0402)
14.1
2+3 rising edge strobe used for the LVDS camera
signals
1+2 falling edge strobe used for the LVDS camera
signals
J31
J31 selects rising, or falling edge strobe for the
LVDS Deserializer at U27 used for the camera
connectivity of the phyFLEX-i.MX 6 (CSI0)
0 Ω
(0402)
14.1
2+3 rising edge strobe used for the LVDS camera
signals
1+2 falling edge strobe used for the LVDS camera
signals
Table 9: Jumper Settings
2
2
: Default settings are in bold blue text
