Phytec phyFLEX-i.MX 6 - Internal Power Domains

Power
 PHYTEC Messtechnik GmbH 2013 L-773e_2
29
4.2.1 Power Domains
External voltages:
 VDD_5V_IN_R 5V main supply voltage
 USB0_VBUS USB0 Bus voltage, must be supplied with
5 V if USB0 is used
 USB1_VBUS USB1 Bus voltage, must be supplied with
5 V if USB1 is used
 PMIC_VBBAT PMIC Backup supply
Internal voltages:
VDD_5V_IN
3
: only used to generate other voltages
Internally generated voltages: VDD_MX6_ARM (1.375 V),
VDD_MX6_SOC (1.375V), VDD_3V3_LOGIC (3.3 V),
VDD_3V3_PMIC_IO (3.3V), VDD_SD0 and VDD_SD1 (3.3V),
VDD_ETH_IO (2.5V) VDD_MX6_SNVS (3.0 V),
VDD_MX6_HIGH (3.0V), VDD_PM (3.3 V), VDD_ETH_1V2
(1.2V), VDD_DDR3_1V5 (1.5 V), DDR3_VTT (0.75 V),
DDR3_VREF (0.75 V)
 VDD_MX6_ARM: i.MX 6 core (VDDARM_IN,
(1.375 V) VDDARM23_IN)
 VDD_MX6_SOC: i.MX 6 SOC (VDDSOC_IN)
(1.375 V)
 VDD_MX6_HIGH: i.MX 6 internal regulator
(3.0 V) (VDDHIGH_IN)
 VDD_MX6_SNVS: i.MX 6 backup supply (VDD_SNVS_IN)
(3.0 V)
 VDD_ETH_IO: i.MX6 RGMII supply (NVCC_RGMII,
(2.5 V) NVCC_ENET), Ethernet PHY RGMII IO
supply
 VDD_ETH_1V2: Ethernet PHY core voltage
(1.2 V)
3
: derived from 5V_IN_R via current sense amplifier at U16
