Phytec phyFLEX-i.MX 6 - phyFLEX-flex Connector X3 Pinout (Row A)

Pin Description
 PHYTEC Messtechnik GmbH 2013 L-773e_2
19
positions (e.g. SATA, CAN, camera). Other phyFLEX SOMs might
have more, or less interfaces.
Pin # Signal ST Voltage Domain Description
X3A1 X_CSI_CLK0P CSI-2_I i.MX 6 internal CSI clock+
X3A2 X_CSI_CLK0M CSI-2_I i.MX 6 internal CSI clock-
X3A3 X_CSI0_DAT10 I VDD_3V3_LOGIC CSI0 data10
X3A4 X_CSI_D0P CSI-2_I i.MX 6 internal CSI data0+
X3A5 X_CSI_D0M CSI-2_I i.MX 6 internal CSI data0-
X3A6 GND - - Ground 0 V
X3A7 X_CSI_D1P CSI-2_I i.MX 6 internal CSI data1+
X3A8 X_CSI_D1M CSI-2_I i.MX 6 internal CSI data1-
X3A9 X_CSI0_DAT11 I VDD_3V3_LOGIC CSI0 data11
X3A10 X_CSI_D2P CSI-2_I i.MX 6 internal CSI data2+
X3A11 X_CSI_D2M CSI-2_I i.MX 6 internal CSI data2-
X3A12 GND - - Ground 0 V
X3A13 X_CSI_D3P CSI-2_I i.MX 6 internal CSI data3+
X3A14 X_CSI_D3M CSI-2_I i.MX 6 internal CSI data3-
X3A15 X_CSI0_DAT12 I VDD_3V3_LOGIC CSI0 data12
X3A16 X_CSI0_DAT13 I VDD_3V3_LOGIC CSI0 data13
X3A17 X_CSI0_DAT14 I VDD_3V3_LOGIC CSI0 data14
X3A18 GND - - Ground 0 V
X3A19 X_CSI0_DAT15 I VDD_3V3_LOGIC CSI0 data15
X3A20 X_CSI0_DAT16 I VDD_3V3_LOGIC CSI0 data16
X3A21 X_CSI0_DAT17 I VDD_3V3_LOGIC CSI0 data17
X3A22 X_CSI0_DAT18 I VDD_3V3_LOGIC CSI0 data18
X3A23 X_CSI0_DAT19 I VDD_3V3_LOGIC CSI0 data19
X3A24 GND - - Ground 0 V
X3A25 X_CSI0_MCLK O VDD_3V3_LOGIC CSI0 master clock
X3A26 X_CSI0_PIXCLK O VDD_3V3_LOGIC CSI0 pixel clock
X3A27 X_CSI0_VSYNC I VDD_3V3_LOGIC CSI0 vertical sync
X3A28 X_CSI0_DATA_EN O VDD_3V3_LOGIC CSI0 data enable
X3A29 X_TAMPER I VDD_3V3_LOGIC Tamper
X3A30 GND - - Ground 0 V
X3A31 X_EIM_WAIT I VDD_3V3_LOGIC EIM wait
X3A32 X_EIM_A24 O VDD_3V3_LOGIC EIM address24
X3A33 X_EIM_A23 O VDD_3V3_LOGIC EIM address23
X3A34 X_EIM_A22 O VDD_3V3_LOGIC EIM address22
X3A35 X_EIM_A21 O VDD_3V3_LOGIC EIM address21
Table 7: Pinout of the phyFLEX-flex Connector X3, Row A
