Phytec phyFLEX-i.MX 6 - Table 10: Standard Phyflex Boot Options; Table 11: Phyflex-I.MX 6 Specific Boot Options

phyFLEX
®
-i.MX 6 [PFL-A-XL1-xxx
34  PHYTEC Messtechnik GmbH 2013 L-773e_2
Boot Mode X_BOOT2 X_BOOT1 X_BOOT0 Bootsource
0 1 1 1
On board memory (e.g.
NAND, SSD, eMMC)
1 (optional) 1 1 0 SPI0
2 (optional) 1 0 1
alternative on board
memory (e.g. SSD,
eMMC)
3 (optional) 1 0 0 SD0 external
4 (optional) 0 1 1 Serial (UART or USB)
5 (optional) 0 1 0 SATA0
6 (optional) 0 0 1 USB0
7 (optional) 0 0 0
specific (e.g. PCIe, I2C,
Ethernet……)
Table 10: Standard phyFLEX Boot Options
The phyFLEX-i.MX 6 specific boot options are shown in the
following table.
Boot Mode X_BOOT2 X_BOOT1 X_BOOT0 Bootsource
0 1 1 1 NAND
1 1 1 0
SPI3, CS0 (on board SPI
Flash if populated, same
as mode 2)
2 1 0 1
SPI3, CS0 (on board SPI
Flash if populated, same
as mode 1)
3 1 0 0 SD0 external
4 0 1 1
Serial USB OTG
(USB0, same as mode 6)
5 0 1 0 SATA
6 0 0 1
Serial USB OTG
(USB0, same as mode 4)
7 0 0 0 Bootconfig from eFUSE
Table 11: phyFLEX-i.MX 6 specific Boot Options
