Phytec phyFLEX-i.MX 6 - JTAG Connector X4 Signal Assignment

Debug Interfaces
 PHYTEC Messtechnik GmbH 2013 L-773e_2
61
Note:
The JTAG connector X4 only populates phyFLEX-i.MX 6 modules
with a specific order option. We recommend integration of a standard
(2 mm pitch) pin header connector in the user target circuitry to allow
easy program updates via the JTAG interface.
Signal
Pin Row*
Signal
A B
VSUPPLY
(VDD_3V3_LOGIC)
2 1 TREF
(VDD_3V3_LOGIC via
0 Ohms)
GND 4 3 X_JTAG_TRSTB
GND 6 5 X_JTAG_TDI
GND 8 7 X_JTAG_TMS
GND 10 9 X_JTAG_TCK
GND 12 11 X_JTAG_RTCK
(connected via 0 Ohms to
X_JTAG_TCK)
GND 14 13 X_JTAG_TDO
GND 16 15 X_PM_nRESET_IN
GND 18 17 not connected
GND 20 19 not connecte
d
Table 29: JTAG Connector X4 Signal Assignment
*Note: Row A is on the controller side of the module and row B is on
the connector side of the module
PHYTEC offers a JTAG-Emulator adapter (order code JA-002) for
connecting the phyFLEX-i.MX 6 to a standard emulator. The JTAG-
Emulator adapter extends the signals of the module’s JTAG connector
to a standard ARM connector with 2 mm pin pitch. The JA-002
therefore functions as an adapter for connecting the module’s non-
ARM-compatible JTAG connector X4 to standard Emulator
connectors.
