Phytec phyFLEX-i.MX 6 - CAN Interface; SATA Interface; Table 23: CAN Interface Signal Location; Table 24: SATA Interface Signal Location

phyFLEX
®
-i.MX 6 [PFL-A-XL1-xxx
52  PHYTEC Messtechnik GmbH 2013 L-773e_2
8.8 CAN Interface
The CAN interface of the phyFLEX-i.MX 6 is connected to the first
FlexCAN module (FlexCAN1) of the i.MX 6 which is a full
implementation of the CAN protocol specification Version 2.0B. It
supports standard and extended message frames and programmable bit
rates of up to 1 Mb/s.
The signals of the CAN interface are brought out on the
phyFLEX-optional connector X2. The following table shows the
position of the signals.
Pin # Signal ST Voltage Domain Description
X2A4 X_CAN0_TXD O VDD_3V3_LOGIC CAN0 transmi
t
X2A5 X_CAN0_RXD I VDD_3V3_LOGIC CAN0 receive
X2A7 reference-voltage REF VDD_3V3_LOGIC
CAN0 reference
voltage
Table 23: CAN Interface Signal Location
8.9 SATA Interface
The SATA II interface of the phyFLEX-i.MX 6 is a high-speed
serialized ATA data link interface compliant with SATA Revision 3.0
(physical layer complies with SATA Revision 2.5) which supports
data rates of up to 3.0 Gbit/s. The interface includes an internal DMA
engine, command layer, transport layer, link layer and the physical
layer. The interface itself supports only one SATA device.
The phyFLEX-i.MX 6 provides an SATA II Interface at the
phyFLEX-optional connector X2 at the following locations:
Pin # Signal ST Voltage Domain Description
X2A10 X_SATA0_TX+ LVDS_O i.MX 6 internal SATA0 transmit lane+
X2A11 X_SATA0_TX- LVDS_O i.MX 6 internal SATA0 transmit lane-
X2A13 X_SATA0_RX+ LVDS_I i.MX 6 internal SATA0 receive lane+
X2A14 X_SATA0_RX- LVDS_I i.MX 6 internal SATA0 receive lane-
Table 24: SATA Interface Signal Location
