8.11 Media Local Bus
The Media Local Bus (MLB) interface provides a link to a MOST®
data network, using the standardized Media Local Bus protocol (up to
150 Mbit/s) for inter-chip communication. The Media Local Bus
interface is implemented as MediaLB 6-pin interface (differential).
The module is backward compatible to MLB-50. The MLB interface
is only available on the not standardized phyFLEX-flex connector X3.
The following table shows the position of the signals on the connector.
Pin # Signal ST
Voltage
Domain
Description
X3B16 X_MLB_DP MLB_I/O i.MX 6 internal
Media local bus data
line+
X3B17 X_MLB_DN MLB_I/O i.MX 6 internal
Media local bus data
line-
X3B19 X_MLB_SP MLB_I/O i.MX 6 internal
Media local bus signal
line+
X3B20 X_MLB_SN MLB_I/O i.MX 6 internal
Media local bus signal
line-
X3B22 X_MLB_CP MLB_O i.MX 6 internal
Media local bus
clock+
X3B23 X_MLB_CN MLB_O i.MX 6 internal
Media local bus
clock-
Table 26: Media Local Bus Interface Signal Location
