Phytec phyFLEX-i.MX 6 - Table 8: Pinout of the Phyflex-Flex Connector X3, Row B

Pin Description
 PHYTEC Messtechnik GmbH 2013 L-773e_2
21
X3B12
X_CSI0_DAT4 I VDD_3V3_LOGIC CSI0 data4
X3B13 X_LVDS1_CLK_P LVDS_O i.MX 6 internal LVDS1 clock+
X3B14 X_LVDS1_CLK_N LVDS_O i.MX 6 internal LVDS1 clock-
X3B15 GND - - Ground 0 V
X3B16 X_MLB_DP MLB_I/O i.MX 6 internal Media local bus data line+
X3B17 X_MLB_DN MLB
_
I/O i.MX 6 internal Media local bus data line-
X3B18 X_CSI0_DAT5 I VDD_3V3_LOGIC CSI0 data5
X3B19 X_MLB_SP MLB_I/O i.MX 6 internal
Media local bus signal
line+
X3B20 X_MLB_SN MLB_I/O i.MX 6 internal
Media local bus signal
line-
X3B21 GND - - Ground 0 V
X3B22 X_MLB_CP MLB_O i.MX 6 internal Media local bus clock+
X3B23 X_MLB_CN MLB_O i.MX 6 internal Media local bus clock-
X3B24 X_CSI0_DAT9 I VDD_3V3_LOGIC CSI0 data9
X3B25 X_EIM_LBA O VDD_3V3_LOGIC EIM load burst address
X3B26 X_EIM_RW O VDD_3V3_LOGIC EIM Read/write
X3B27 GND - - Ground 0 V
X3B28 X_CSI0_DAT8 I VDD_3V3_LOGIC CSI0 data8
X3B29 X_EIM_OE O VDD_3V3_LOGIC EIM output enable
X3B30 X_EIM_BCLK O VDD_3V3_LOGIC EIM burst clock
X3B31 X_EIM_DA13 I/O VDD_3V3_LOGIC EIM address/data13
X3B32 X_EIM
_
DA14 I/O VDD_3V3_LOGIC EIM address/data14
X3B33 GND - - Ground 0 V
X3B34 X_EIM_DA15 I/O VDD_3V3_LOGIC EIM address/data15
X3B35 X_CLK2_P
LVDS_I/
O
i.MX 6 internal Differential clock2+
X3B36 X_CLK2_N
LVDS_I/
O
i.MX 6 internal Differential clock2-
X3B37 X_GPIO_16 I/O VDD_3V3_LOGIC GPIO16
X3B38 X_EIM_D22 I/O VDD_3V3_LOGIC EIM data22
X3B39 GND - - Ground 0 V
X3B40 X_CSI0_DAT7 I VDD_3V3_LOGIC CSI0 data7
X3B41 X_CSI0_DAT6 I VDD_3V3_LOGIC CSI0 data6
X3B42 X_KEY_COL1 I/O VDD_3V3_LOGIC Keypad column1
X3B43 X_KEY_ROW1 I/O VDD_3V3_LOGIC Keypad row1
X3B44 PMIC_VBBAT PWR_I 2V – 5V
PMIC Backup power
supply
X3B45 GND - - Ground 0 V
X3B46 VDD_MX6_SNVS PWR_I 3V
i.MX6 Backup power
supply (normally
generated by PMIC)
Table 8: Pinout of the phyFLEX-flex Connector X3, Row B (continued)
