X3B47
X_DI0_DISP_CLK O VDD_3V3_LOGIC DI0 display clock
X3B48 X_DI0_PIN4 O VDD_3V3_LOGIC DI0 pin4
X3B49 X_DISP0_DAT6 O VDD_3V3_LOGIC DISP0 data6
X3B50 X_DISP0_DAT7 O VDD_3V3_LOGIC DISP0 data7
X3B51 GND - - Ground 0 V
X3B52 X_DISP0_DAT10 O VDD_3V3_LOGIC DISP0 data10
X3B53 X_DISP0_DAT11 O VDD_3V3_LOGIC DISP0 data11
X3B54 X_DISP0_DAT12 O VDD_3V3_LOGIC DISP0 data12
X3B55 X_DISP0_DAT15 O VDD_3V3_LOGIC DISP0 data15
X3B56 X_DISP0_DAT20 O VDD_3V3_LOGIC DISP0 data20
X3B57 GND - - Ground 0 V
X3B58 X_DISP0_DAT21 O VDD_3V3_LOGIC DISP0 data21
X3B59 X_DISP0_DAT22 O VDD_3V3_LOGIC DISP0 data22
X3B60 X_DISP0_DAT23 O VDD_3V3_LOGIC DISP0 data23
Table 8: Pinout of the phyFLEX-flex Connector X3, Row B (continued)
Caution! Signals on the phyFLEX-optional connector (X3) are
module specific. This connector has only fixed Ground signals. All
other signals of the phyFLEX-flex connector depend on the features of
the controller populating the SOM.
