4 Power
The phyFLEX-i.MX 6 operates off of a single power supply voltage.
The following sections of this chapter discuss the primary power pins
on the phyFLEX-Connector X1 in detail.
4.1 Primary System Power (VDD_5V_IN_R)
The phyFLEX-i.MX 6 operates off of a primary voltage supply with a
nominal value of +5 V. On-board switching regulators generate the
3.3 V, 2.5 V, 1.375 V, 1.5 V, 0.75 V, 1.2 V and 3 V voltage supplies
required by the i.MX 6 MCU and on-board components from the
primary 5 V supplied to the SOM.
For proper operation the phyFLEX-i.MX 6 must be supplied with a
voltage source of 5 V 5 % with 2 A load at the VCC pins on the
phyFLEX-Connector X1.
VDD_5V_IN_R: X1 A1, A2, A3, B1, B2, B3
Connect all +5 V VCC input pins to your power supply and at least
the matching number of GND pins.
Corresponding GND: X1 A4, A10, A16, B4, B7, B13
Please refer to section 2 for information on additional GND Pins
located at the phyFLEX-Connector X1.
Caution:
As a general design rule we recommend connecting all GND pins
neighboring signals which are being used in the application circuitry.
For maximum EMI performance all GND pins should be connected to
a solid ground plane.
