Phytec phyFLEX-i.MX 6 - Signal Configuration (J9 and J31); Table 36: LVDS Signal Configuration J9 and J31

LVDS Camera Interface
 PHYTEC Messtechnik GmbH 2013 L-773e_2
67
14.1 Signal Configuration (J9 and J31)
J9 selects rising, or falling edge strobe for the LVDS Deserializer at
U12 used for the camera connectivity of the phyFLEX-i.MX 6 CSI1
port.
J31 selects rising, or falling edge strobe for the LVDS Deserializer at
U27 used for the camera connectivity of the phyFLEX-i.MX 6 CSI0
port.
Position Description Type
2+3 risin
g
ed
g
e strobe used for the LVDS camera
signals
0R
(0402)
1+2 falling edge strobe used for the LVDS camera
signals
Table 36: LVDS Signal Configuration J9 and J31
