phyFLEX
®
-i.MX 6 [PFL-A-XL1-xxx
20 PHYTEC Messtechnik GmbH 2013 L-773e_2
X3A36 GND - - Ground 0 V
X3A37 X_EIM_A20 O VDD_3V3_LOGIC EIM address20
X3A38 X_EIM_A19 O VDD_3V3_LOGIC EIM address19
X3A39 X_EIM_A18 O VDD_3V3_LOGIC EIM address18
X3A40 X_EIM_A17 O VDD_3V3_LOGIC EIM address17
X3A41 X_EIM_EB0 O VDD_3V3_LOGIC EIM enable byte0
X3A42 GND - - Ground 0 V
X3A43 X_EIM_EB1 O VDD_3V3_LOGIC EIM enable byte1
X3A44 X_EIM_DA0 I/O VDD_3V3_LOGIC EIM address/data0
X3A45 X_EIM_DA1 I/O VDD_3V3_LOGIC EIM address/data1
X3A46 X_EIM_DA2 I/O VDD_3V3_LOGIC EIM address/data2
X3A47 X_EIM_DA3 I/O VDD_3V3_LOGIC EIM address/data3
X3A48 GND - - Ground 0 V
X3A49 X_EIM_DA4 I/O VDD_3V3_LOGIC EIM address/data4
X3A50 X_EIM_DA5 I/O VDD_3V3_LOGIC EIM address/data5
X3A51 X_EIM_DA6 I/O VDD_3V3_LOGIC EIM address/data6
X3A52 X_EIM_DA7 I/O VDD_3V3_LOGIC EIM address/data7
X3A53 X_EIM_DA8 I/O VDD_3V3_LOGIC EIM address/data8
X3A54 GND - - Ground 0 V
X3A55 X_EIM_DA9 I/O VDD_3V3_LOGIC EIM address/data9
X3A56 X_EIM_DA10 I/O VDD_3V3_LOGIC EIM address/data10
X3A57 X_EIM_DA11 I/O VDD_3V3_LOGIC EIM address/data11
X3A58 X_EIM_DA12 I/O VDD_3V3_LOGIC EIM address/data12
X3A59 X_EIM_A16 O VDD_3V3_LOGIC EIM address16
X3A60 GND - - Ground 0 V
Table 7: Pinout of the phyFLEX-flex Connector X3, Row A (continued)
Pin # Signal ST Votlage domain Description
X3B1 X_LVDS1_TX0_P LVDS_O i.MX 6 internal LVDS1 data0+
X3B2 X_LVDS1_TX0_N LVDS_O i.MX 6 internal LVDS1 data0-
X3B3 GND - - Ground 0 V
X3B4 X_LVDS1_TX1_P LVDS_O i.MX 6 internal LVDS1 data1+
X3B5 X_LVDS1_TX1_N LVDS_O i.MX 6 internal LVDS1 data1-
X3B6
X_DISP0_DAT9/PWM
2_PWMO
O VDD_3V3_LOGIC
DISP0 data9/PWM2
output
X3B7 X_LVDS1_TX2_P LVDS_O i.MX 6 internal LVDS1 data2+
X3B8 X_LVDS1_TX2_N LVDS_O i.MX 6 internal LVDS1 data2-
X3B9 GND - - Ground 0 V
X3B10 X_LVDS1_TX3_P LVDS_O i.MX 6 internal LVDS1 data3+
X3B11 X_LVDS1_TX3_N LVDS_O i.MX 6 internal LVDS1 data3-
Table 8: Pinout of the phyFLEX-flex Connector X3, Row B
