Phytec phyFLEX-i.MX 6 - Page 46

phyFLEX
®
-i.MX 6 [PFL-A-XL1-xxx
30  PHYTEC Messtechnik GmbH 2013 L-773e_2
 VDD_SD0: i.MX6 SD3 supply (NVCC_SD3)
(3.3 V)
 VDD_SD1: i.MX6 SD2 supply (NVCC_SD2)
(3.3 V)
 VDD_PM: CMIC supply
(3.3 V)
 VDD_3V3_PMIC_IO: PMIC IO supply
(3.3 V)
 VDD_DDR3_1V5: i.MX 6 DDR (NVCC_DRAM), RAM
(1.5 V) devices
 DDR3_VTT: RAM devices termination voltage
(0.75 V)
 DDR3_VREF: i.MX 6 DDR3 reference voltage
(0.75 V) (DRAM_VREF), RAM devices
reference voltage
 VDD_3V3_LOGIC: i.MX 6 pad supply (NVCC_NANDF,
(3.3 V) NVCC_JTAG, NVCC_LCD,
NVCC_CSI, NVCC_EIM,
NVCC_GPIO), I2C EEPROM, SPI
Flash, NAND Flash, Camera
Deserializer, Ethernet PHY, EMIC
