Phytec phyFLEX-i.MX 6 - phyFLEX-optional Connector X2 Pinout (Row B)

Pin Description
 PHYTEC Messtechnik GmbH 2013 L-773e_2
17
X2A38 N.C. - - Not connected
X2A39 N.C. - - Not connected
X2A40 X_CAMERA0_L0+ LVDS_I VDD_3V3_LOGIC Camera0 data+
X2A41 X_CAMERA0_L0- LVDS_I VDD_3V3_LOGIC Camera0 data-
X2A42 GND - - Ground 0 V
X2A43 X_CAMERA0_CL
K
O VDD_3V3_LOGIC Camera0 master clock
X2A44 reference-voltage REF_O VDD_3V3_LOGIC Camera0 reference voltage
X2A45 RSVD - - reserved
X2A46 X_CAMERA1_L0+ LVDS_I VDD_3V3_LOGIC Camera1 data+
X2A47 X_CAMERA1_L0- LVDS_I VDD_3V3_LOGIC Camera1 data-
X2A48 GND - - Ground 0 V
X2A49 X_CAMERA1_CLK O VDD_3V3_LOGIC Camera1 master clock
X2A50 reference-voltage REF_O VDD_3V3_LOGIC Camera1 reference voltage
Table 5: Pinout of the phyFLEX-optional Connector X2, Row A (continued)
Pin # Signal ST Voltage Domain Description
X2B1 X_HDMI0_TMDS_DATA2+
TMDS_
O
i.MX 6 internal HDMI0 data2+
X2B2 X_HDMI0_TMDS_DATA2-
TMDS_
O
i.MX 6 internal HDMI0 data2-
X2B3 GND - - Ground 0 V
X2B4 X_HDMI0_TMDS_DATA1+
TMDS_
O
i.MX 6 internal HDMI0 data1+
X2B5 X_HDMI0_TMDS_DATA1-
TMDS_
O
i.MX 6 internal HDMI0 data1-
X2B6 reference-voltage REF_O VDD_3V3_LOGIC
HDMI0 reference
voltage
X2B7 X_HDMI0_TMDS_DATA0+
TMDS_
O
i.MX 6 internal HDMI0 data0+
X2B8 X_HDMI0_TMDS_DATA0-
TMDS_
O
i.MX 6 internal HDMI0 data0-
X2B9 GND - - Ground 0 V
X2B10 X_HDMI0_TMDS_CLOCK+
TMDS_
O
i.MX 6 internal HDMI0 clock+
X2B11 X_HDMI0_TMDS_CLOCK-
TMDS_
O
i.MX 6 internal HDMI0 clock-
X2B12 X_HDMI0_CEC I/O VDD_3V3_LOGIC HDMI0 CEC
X2B13 X_HDMI0_nHPD I VDD_3V3_LOGIC
HDMI0 hot plug
detect
X2B14 N.C. - - Not connected
X2B15 GND - - Ground 0 V
X2B16 N.C. - - Not connected
Table 6: Pinout of the phyFLEX-optional Connector X2, Row B
