Phytec phyFLEX-i.MX 6 - Page 58

phyFLEX
®
-i.MX 6 [PFL-A-XL1-xxx
42  PHYTEC Messtechnik GmbH 2013 L-773e_2
Pin # Signal ST
Voltage
Domain
Description
X1B22 X_SD0_D7 I/O VDD_SD0 SD0 data 7
X2A15 X_SD1_D3 I/O VDD_SD1 SD1 data 3
X2A16 X_SD1_CMD O VDD_SD1 SD1 command
X2A17 X_SD1_CLK O VDD_SD1 SD1 clock
X2A19 reference-voltage REF_O VDD_SD1
SD1 reference
voltage
X2A20 X_SD1_nWP I VDD_SD1
SD1 write protec-
tion (active low)
X2A21 X_SD1_nCD I VDD_SD1
SD1 card detection
(active low)
X2A22 X_SD1_D0 I/O VDD_SD1 SD1 data 0
X2A23 X_SD1_D1 I/O VDD_SD1 SD1 data 1
X2A25 X_SD1_D2 I/O VDD_SD1 SD1 data 2
Table 15: Location of SD/ MMC Card Interface Signals (continued)
