Phytec phyFLEX-i.MX 6 - Page 72

phyFLEX
®
-i.MX 6 [PFL-A-XL1-xxx
56  PHYTEC Messtechnik GmbH 2013 L-773e_2
Pin # Signal ST Voltage Domain Description
X1A63 X_GPIO7 I/O VDD_3V3_LOGIC
General purpose
input/output 7
(GPIO7_13 of i.MX 6)
X1A65 X_GPIO8 I/O VDD_3V3_LOGIC
General purpose
input/output 8
(GPIO4_5 of i.MX 6)
X1A66 X_GPIO9 I/O VDD_3V3_LOGIC
General purpose
input/output 9
(GPIO2_23 of i.MX 6)
X1A67 X_GPIO10 I/O VDD_3V3_LOGIC
General purpose
input/output 10
(GPIO2_24 of i.MX 6)
Table 27: Location of GPIO Pins (continued)
Beside these 11 dedicated GPIOs, most of the i.MX 6 signals which
are connected directly to the module connector can be configured to
act as GPIOs, due to the multiplexing functionality of most controller
pins.
