Technical Specifications
PHYTEC Messtechnik GmbH 2013 L-773e_2
71
Connectors on the phyFLEX-i.MX 6:
Manufacturer Samtec
phyFLEX-fix (X1):
Number of pins per contact rows 160 pins (2 rows of 80 pins each)
Samtec part number (lead free) BSH-080-01-L-D-A-K-TR
phyFLEX-optional (X2):
Number of pins per contact rows 100 pins (2 rows of 50 pins each)
Samtec part number (lead free) BSH-050-01-L-D-A-K-TR
phyFLEX-flex (X3):
Number of pins per contact rows 120 pins (2 rows of 60 pins each)
Samtec part number (lead free) BSH-060-01-L-D-A
The following list shows the receptacle sockets that correspond to the
connectors populating the underside of the phyFLEX—i.MX 6. The
given connector height indicates the distance between the two
connected PCBs when the module is mounted on the corresponding
carrier board. In order to get the exact spacing, the maximum
component height (3 mm) on the bottom side of the phyFLEX must be
subtracted.
Connector height 5 mm
Manufacturer Samtec
Number of pins per contact row 160 pins (2 rows of 80 pins each)
Samtec part number (lead free) ASP-167037-01
(BTH-080-01-L-D-A-K-TR)
PHYTEC part number (lead free) VM245
Number of pins per contact row 100 pins (2 rows of 50 pins each)
Samtec part number (lead free) BTH-050-01-L-D-A-K-TR
PHYTEC part number (lead free) VM247
Number of pins per contact row 120 pins (2 rows of 60 pins each)
Samtec part number (lead free) BTH-060-01-L-D-A
PHYTEC part number (lead free) VM240
Please refer to the corresponding data sheets and mechanical
specifications provided by Samtec (www.samtec.com).
