PI E-727 User Manual

User Manual
E727T0005, valid for E-727
BRO, 2019-06-28
Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 182 / 240
Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws
Command Format Short Description
DRR? DRR? [<StartPoint> <NumberOfPoints>
[{<RecTableID>}]]
Get Recorded Data Values
DRT DRT {<RecTableID> <TriggerSource>
<Value>}
Set Data Recorder Trigger Source
DRT? DRT? [{<RecTableID>}] Get Data Recorder Trigger Source
DTC DTC {<DDLtableID>} Clear DDL Table Data
DTL?
DTL? [{<DDLtableID>}]
Get DDL Table Length
ERR?
ERR?
Get Error Number
GWD? GWD? [<StartPoint>
<NumberOfPoints> [{<WaveTableID>}]]
Get Wave Table Data
HDI? HDI? Get Help For Interpretation Of DIA? Response
HDR? HDR? Get All Data Recorder Options
HLP? HLP? Get List Of Available Commands
HLT HLT [{<AxisID>}] Halt Motion Smoothly
HPA?
HPA?
Get List Of Available Parameters
HPV?
HPV?
Get Parameter Value Description
IDN? IDN? Get Device Identification
IFC IFC {<InterfacePam> <PamValue>} Set Interface Parameters Temporarily
IFC? IFC? [{<InterfacePam>}] Get Current Interface Parameters
IFS
IFS <Pswd> {<InterfacePam>
<PamValue>}
Set Interface Parameters As Default Values
IFS?
IFS? [{<InterfacePam>}]
Get Interface Parameters As Default Values
IMP IMP <AxisID> <Amplitude> Start Impulse And Response Measurement
JOG JOG {<AxisID> <Velocity>} Start Motion With Given Velocity
JOG? JOG? [{<AxisID>}] Get Velocity For Motion Caused By JOG
JRC JRC <Jump> <CMD?> <OP> <Value> Jump Relatively Depending On Condition
MAC
MAC <keyword> {<parameter>}
Especially:
MAC BEG <macroname>
MAC DEF <macroname>
MAC DEF?
MAC DEL <macroname>
MAC END
MAC ERR?
MAC FREE?
MAC NSTART <macroname> <uint>
[<String1> [<String2>]]
MAC START <macroname> [<String1>
[<String2>]]
Call Macro Function
