Command Format Short Description
TPC? TPC? Get Number of Output Signal Channels
TSC? TSC? Get Number of Input Signal Channels
TSP? TSP? [{<InputSignalID>}] Get Input Signal Value
TWC
TWC
Clear All Wave Related Triggers
TWG?
TWG?
Get Number of Wave Generators
TWS TWS {<TrigOutID> <PointNumber>
<Switch>}
Set Trigger Line Action To Waveform Point
TWS? TWS? [<StartPoint>
[<NumberOfPoints> [{<TrigOutID>}]]]
Get Trigger Line Action At Waveform Point
VAR VAR <Variable> <String> Set Variable Value
VAR? VAR? [{<Variable>}] Get Variable Value
VCO VCO {<AxisID> <VelCtrlState>} Set Velocity Control Mode
VCO? VCO? [{<AxisID>}] Get Velocity Control Mode
VEL
VEL {<AxisID> <Velocity>}
Set Closed-Loop Velocity
VEL? VEL? [{<AxisID>}] Get Closed-Loop Velocity
VOL? VOL? [{<OutputSignalID>}] Get Voltage Of Output Signal Channel
WAC WAC <CMD?> <OP> <Value> Wait For Condition
WAV WAV <WaveTableID> <AppendWave>
<WaveType> <WaveTypeParameters>
Set Waveform Definition
WAV? WAV? [{<WaveTableID>
<WaveParameterID>}]
Get Waveform Definition
WCL
WCL {<WaveTableID>}
Clear Wave Table Data
WGC
WGC {<WaveGenID> <Cycles>}
Set Number Of Wave Generator Cycles
WGC? WGC? [{<WaveGenID>}] Get Number Of Wave Generator Cycles
WGO WGO {<WaveGenID> <StartMode>} Set Wave Generator Start/Stop Mode
WGO? WGO? [{<WaveGenID>}] Get Wave Generator Start/Stop Mode
WGR WGR Starts Recording In Sync With Wave Generator
WOS WOS {<WaveGenID> <Offset>} Set Wave Generator Output Offset
WOS?
WOS? [{<WaveGenID>}]
Get Wave Generator Output Offset
WPA WPA <Pswd> [{<ItemID> <PamID>}] Save Parameters To Nonvolatile Memory
WSL WSL {<WaveGenID> <WaveTableID>} Set Connection Of Wave Table To Wave Generator
WSL WSL? [{<WaveGenID>}] Get Connection Of Wave Table To Wave Generator
WTR WTR {<WaveGenID> <WaveTableRate>
<InterpolationType>}
Set Wave Generator Table Rate
WTR? WTR? [{<WaveGenID>}] Get Wave Generator Table Rate
