PI E-727 User Manual

User Manual
E727T0005, valid for E-727
BRO, 2019-06-28
Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 192 / 240
Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws
Parameter
ID (hexa-
decimal)
Data
Type
Command
Level for
Write
Access
Item Type Parameter
Name
Description
0x03003800 FLOAT 2 Input signal
channel
CBI Calibration parameters required
with models for piezoresistive
sensors and strain gauge sensors;
SBI = Sensor Bridge Impedance of
the connected sensor (94000 if
no mechanics is connected)
0x03003801 FLOAT 3 Input signal
channel
SBI
0x03003803 FLOAT 3 Input signal
channel
OAI
0x05000000 INT 1 Input signal
channel
Digital Filter
Type
ID-chip
Digital filtering of the input
signals. For details, see “Digital
Processing”, p. 27.
0x05000001 FLOAT 1 Input signal
channel
Digital Filter
Bandwidth
0x05000101
FLOAT
1
Input signal
channel
User Filter
Param. 1
Coefficients for the USER filter
type. For further details, see
“Digital Processing”, p. 27.
0x05000102 FLOAT 1 Input signal
channel
User Filter
Param. 2
0x05000103 FLOAT 1 Input signal
channel
User Filter
Param. 3
0x05000104
FLOAT
1
Input signal
channel
User Filter
Param. 4
0x05000105 FLOAT 1 Input signal
channel
User Filter
Param. 5
0x06000500 INT 1 System ADC Channel for
Target
Enable the analog control input
for an axis. For details, see “Use
as Control Value Generation
Source”, p. 90
0x06000501
FLOAT
1
System
Analog Target
Offset
0x07000000 FLOAT 1 Axis Range Limit min ID-chip
0x07000001 FLOAT 1 Axis Range Limit max ID-chip
0x07000200 FLOAT 1 Axis Servo Loop
Slew-Rate
ID-chip
For details, see p. 35.
0x07000201 FLOAT 1 Axis Open Loop
Slew-Rate
0x07000300
FLOAT
1
Axis
Servo-loop P-
Term
ID-chip
Parameters of the PID algorithm
(position control). For details, see
p. 35.
0x07000301 FLOAT 1 Axis Servo-loop I-
Term
0x07000302 FLOAT 1 Axis Servo-loop D-
Term
