PI E-727 User Manual

User Manual
E727T0005, valid for E-727
BRO, 2019-06-28
Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 193 / 240
Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws
Parameter
ID (hexa-
decimal)
Data
Type
Command
Level for
Write
Access
Item Type Parameter
Name
Description
0x07000500 FLOAT 1 Axis Position from
Sensor 1
ID-chip
Coefficients of the input matrix.
For details, see “Allocation of
input signal channels to axes”,
p. 29.
0x07000501 FLOAT 1 Axis Position from
Sensor 2
0x07000502 FLOAT 1 Axis Position from
Sensor 3
0x07000503 FLOAT 1 Axis Position from
Sensor 4
0x07000504 FLOAT 1 Axis Position from
Sensor 5
0x07000505
FLOAT
1
Axis
Position from
Sensor 6
0x07000506 FLOAT 1 Axis Position from
Sensor 7
0x07000600 CHAR 1 Axis Axis Name ID-chip
0x07000601 CHAR 1 Axis Axis Unit ID-chip
0x07000800 INT 1 Axis Power Up Servo
ON Enable
For details, see “Control Value
Generation”, p. 30.
0x07000802 INT 1 Axis Power Up
AutoZero
Enable
For details, see “AutoZero
Procedure”, p. 62.
0x07000900
FLOAT
1
Axis
ON Target
Tolerance
ID-chip
[µm]
Gives the settling window. The
settling window is centered
around the axis target position.
The on-target status of an axis is
true when the current axis
position is inside the settling
window and stays there for at
least the settling time (Settling
Time parameter, ID 0x07000901).
0x07000901 FLOAT 1 Axis Settling Time [s]
0x07000a00
FLOAT
1
Axis
AutoZero Low
Voltage
ID-chip
For details, see “AutoZero
Procedure”, p. 62.
0x07000a01 FLOAT 1 Axis AutoZero High
Voltage
0x07000c01 FLOAT 1 Axis Default voltage ID-chip
