Parameter
ID (hexa-
decimal)
Data
Type
Command
Level for
Write
Access
Item Type Parameter
Name
Description
When the selected data type is
floating point (IEEE 754) then this
parameter has no effect.
0x10000503 FLOAT 1 Axis FastIF Data High
Limit
Upper limit for the data sent via
data segment 1 of the SPI
interface.
Must be set when any integer
data type is selected (Fast IF Data
Type, 0x10000501) so that the
scaling can be calculated
internally.
When the selected data type is
floating point (IEEE 754) then this
parameter has no effect.
0x10000504 FLOAT 3 Axis FastIF Used Low
Limit
Currently used lower limit for the
data sent via data segment 1 of
the SPI interface.
For further details, see
“Configuring the Limits for
Position Scaling” (p. 145).
0x10000505 FLOAT 3 Axis FastIF Used High
Limit
Currently used upper limit for the
data sent via data segment 1 of
the SPI interface.
For further details, see
“Configuring the Limits for
Position Scaling” (p. 145).
0x10000506 INT 1 System Used Range For
Fast IF
Determines which limits are used
for scaling the data sent via data
segment 1 of the SPI interface.
For further details, see
“Configuring the Limits for
Position Scaling” (p. 145).
0x10000507 FLOAT 3 Axis FastIF Open
Loop Low Limit
Currently used lower limit for the
input data sent via data segment
1 of the SPI interface, applied in
open-loop operation.
For further details, see
“Configuring the Limits for
Position Scaling” (p. 145).
0x10000508 FLOAT 3 Axis FastIF Open
Loop High Limit
Currently used upper limit for the
input data sent via data segment
1 of the SPI interface, applied in
open-loop operation.
