Parameter
ID (hexa-
decimal)
Data
Type
Command
Level for
Write
Access
Item Type Parameter
Name
Description
For further details, see
“Configuring the Limits for
Position Scaling” (p.
145).
0x10000509 FLOAT 1 System FastIF Open
Loop Limit
Extend
Necessary to cover the whole
travel range in open-loop
operation.
For further details, see
“Configuring the Limits for
Position Scaling” (p. 145).
0x10000800 FLOAT 1 Axis FieldbusAxis
Resolution
Scaling factor for target and
current values transmitted via
EtherCAT interface
For further details, see “EtherCAT
Interface” (p. 164).
0x10000801 INT 3 Axis Fieldbus Set-
Point List Size
Size of input buffer for profile
position mode (max. number of
value sets)
For further details, see “EtherCAT
Interface” (p. 164).
0x11000400 INT 1 System Uart Baudrate
For details, see “Communication”
(p. 56).
0x11000600 CHAR 1 System IP-Address
0x11000700 CHAR 1 System IP-Mask
0x11000800
INT
1
System
IP-Configura-
tion
0x11000b00 CHAR 2 System MAC-Address
0x13000004 INT 3 System Max Wave
Points
For details, see “Wave
Generator” (p. 99).
0x13000109
INT
1
System
Wave Generator
Table Rate
0x1300010a INT 3 System Number of
Waves
0x1300010b FLOAT 1 Axis Wave Offset
0x13000202 INT 1 System Wave Multi
Start By Trigger
