PI E-727 User Manual

User Manual
E727T0005, valid for E-727
BRO, 2019-06-28
Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 203 / 240
Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws
Parameter
ID (hexa-
decimal)
Data
Type
Command
Level for
Write
Access
Item Type Parameter
Name
Description
0x18000209 FLOAT 1 Digital
output
CTO Stop
Threshold
0x18000210 INT 1 Digital
output
CTO Trigger Out
Mask
0x18000300 INT 1 Digital
Output Line
Pos. Distance
Trig. Single
Direction
Additional settings for the
“Position Distance” trigger mode.
For details, see „Example—
"Position Distance" Trigger
Mode“ on p. 71.
0x18000301 FLOAT 1 Digital
Output Line
Pos. Distance
Trig. Filter Time
0x18000302 FLOAT 1 Digital
Output Line
Pos. Distance
Trig. Filter Level
0x18000400
INT
1
Digital
Output Line
Pos. Distance
Trig. High Time
Definition
0x18000401 FLOAT 1 Digital
Output Line
Pos. Distance
Trig. High Time
0xffff0001 INT 2 Firmware
Unit
firmware mark
0xffff0002
INT
2
Firmware
Unit
firmware CRC
0xffff0003 INT 2 Firmware
Unit
firmware desc.
CRC
0xffff0004 INT 2 Firmware
Unit
firmware desc.
version
0xffff0006
CHAR
2
Firmware
Unit
firmware
matchcode
0xffff0007 CHAR 2 Firmware
Unit
hardware
matchcode
0xffff0008 INT 2 Firmware
Unit
firmware
version
0xffff000b INT 2 Firmware
Unit
firmware max.
size
0xffff000c CHAR 2 Firmware
Unit
firmware device
0xffff000d CHAR 2 Firmware
Unit
short
description of
firmware
