Pitco SSH Series - Pitco Gas Valve Vent Tube Cleaning

PitcoSolsticeandSolsticeSupremeHighEfficiencyGasFryers



SG/SSHSeriesServiceManual 13
CleaningtheGasValveVentTube
1. Bend the gas valve vent tube to allow for
removal.
2. Loosen nut at the base of the vent tube with a
3/8 inch open-ended wrench and then remove.
3. Clean the tube (not shown) and reinstall.
NOTE: Make sure the vent tube is not
reinstalled in an upright position
and there are no kinks in the tube.
