PitcoSolsticeandSolsticeSupremeHighEfficiencyGasFryers



SG/SSHSeriesServiceManual 55
ReplacingtheThermostat
1. Remove the two (2) bolt clamp screws that hold
down the temperature probes using a Phillips
screwdriver.
2. Remove the two (2) screws on the thermostat
using a 5/16 inch socket.
3. Remove the thermostat knob.
4. Remove the two (2) screws that hold the
thermostat using a Phillips screwdriver.
Hi-Limit
Thermostat
5. Pull out the thermostat.
