Pitco SSH Series - Pitco Filter Pump and Motor Removal

PitcoSolsticeandSolsticeSupremeHighEfficiencyGasFryers



SG/SSHSeriesServiceManual 68
ReplacingtheFilterPumpandMotor
RemovingtheFilterPumpandMotor
1. Loosen the pump inlet tube using a crescent
wrench.
2. Unscrew and remove the inlet valve of the filter
pump system.
3. Pull out pump inlet tube.
4. Remove filter pan cover (not shown).
5. Disconnect the connections and power supply
cords from the filter pump.
6. Remove the lower connection at the 3-way
return valve using a 15/16 inch wrench.
