Pitco SSH Series - Pitco Basket Lift Component Replacement; Pitco Basket Lift Transformer Replacement

PitcoSolsticeandSolsticeSupremeHighEfficiencyGasFryers



SG/SSHSeriesServiceManual 44
ReplacingtheBasketLiftComponents
RemovingtheBasketLiftCover
1. Remove the six (6) screws, which hold the back
of the basket lift cover, using a 5/16 inch socket.
2. Lift up the back and remove.
ReplacingtheTransformer
1. Remove the two (2) screws, which hold the
transformer, using a 5/16 inch socket.
2. Remove all wires on transformer box using
needle-nose pliers. See “Wiring Diagram –
Basket Lifts” on page 91.
3. Follow steps 1 through 2 in reverse to reinstall
new transformer box.
