Pitco SSH Series User Manual

PitcoSolsticeandSolsticeSupremeHighEfficiencyGasFryers



SG/SSHSeriesServiceManual 24
ReplacingtheIgnitionModule
1. Remove one (1) screw, which hold the ignition
module, using a 5/16 inch socket.
2. Pull the module box and bracket toward the
front of the unit, and then to the right.
3. Disconnect the plug.
4. Remove the ignition wire.
5. Remove the two (2) screws, which hold the
module on the plate, using a Phillips
screwdriver.
6. Remove the harness pins using needle-nose
pliers.
7. Follow steps 1 through 6 in reverse.

Pitco SSH Series Specifications

General

Brand	Pitco
Model	SSH Series
Category	Fryer
Language	English
